Snug Stowing Anchor
Snug Stowing Anchor Introduction
Marine Snug Stowing Anchor is made by Casting Steel. The structure is simple and easy to install, proven high holding power, good stability, used as the bower anchor at large yachts or cruise vessels.
The anchors are of high quality and good stability. The weight of the Anchor is 90kgs to 20000kgs.
The Snug Stowing Anchor can be supplied with certification from any of the major classification societies.
Snug Stowing Anchor Drawing
Snug Stowing Anchor Drawing
Snug Stowing Anchor Specification
| Anchor Weight |
A | B | C | G | L |
| Kg | mm | mm | mm | mm | mm |
| 90 | 755 | 406 | 505 | 302 | 745 |
| 113 | 836 | 438 | 544 | 326 | 804 |
| 136 | 889 | 465 | 579 | 346 | 855 |
| 154 | 917 | 485 | 604 | 361 | 891 |
| 181 | 978 | 512 | 637 | 381 | 940 |
| 204 | 1018 | 533 | 663 | 397 | 979 |
| 227 | 1055 | 552 | 687 | 411 | 1014 |
| 284 | 1136 | 595 | 740 | 443 | 1092 |
| 340 | 1207 | 632 | 786 | 470 | 1160 |
| 397 | 1271 | 665 | 828 | 495 | 1222 |
| 454 | 1329 | 696 | 865 | 518 | 1277 |
| 568 | 1432 | 749 | 932 | 558 | 1377 |
| 681 | 1521 | 796 | 991 | 593 | 1462 |
| 794 | 1601 | 838 | 1043 | 624 | 1538 |
| 851 | 1639 | 858 | 1067 | 638 | 1575 |
| 907 | 1674 | 876 | 1090 | 652 | 1609 |
| 1134 | 1803 | 943 | 1174 | 702 | 1733 |
| 1360 | 1916 | 1003 | 1248 | 746 | 1842 |
| 1475 | 1969 | 1030 | 1282 | 767 | 1892 |
| 1590 | 2018 | 1056 | 1314 | 786 | 1940 |
| 1705 | 2066 | 1081 | 1345 | 804 | 1986 |
| 1814 | 2109 | 1103 | 1373 | 821 | 2027 |
| 2041 | 2193 | 1148 | 1428 | 854 | 2108 |
| 2268 | 2272 | 1187 | 1479 | 884 | 2184 |
| 2495 | 2345 | 1227 | 1527 | 913 | 2254 |
| 2722 | 2414 | 1297 | 1572 | 940 | 2321 |
| 2949 | 2479 | 1330 | 1614 | 966 | 2381 |
| 3175 | 2541 | 1330 | 1655 | 990 | 2443 |
| 3289 | 2571 | 1345 | 1674 | 1001 | 2472 |
| 3402 | 2600 | 1361 | 1693 | 1013 | 2500 |
| 3629 | 2657 | 1390 | 1730 | 1035 | 2554 |
| 3856 | 2711 | 1419 | 1765 | 1056 | 2606 |
| 4082 | 2763 | 1446 | 1799 | 1076 | 2656 |
| 4309 | 2814 | 1472 | 1832 | 1096 | 2705 |
| 4536 | 2862 | 1498 | 1864 | 1115 | 2751 |
| 4763 | 2909 | 1522 | 1894 | 1133 | 2797 |
| 4990 | 2955 | 1546 | 1924 | 1151 | 2840 |
| 5217 | 2999 | 1569 | 1934 | 1168 | 2863 |
| 5443 | 3042 | 1575 | 1950 | 1170 | 2883 |
| 5670 | 3084 | 1597 | 1977 | 1194 | 2923 |
| 5897 | 3124 | 1605 | 1986 | 1200 | 2937 |
| 6124 | 3164 | 1628 | 2015 | 1217 | 2979 |
| 6350 | 3202 | 1648 | 2039 | 1232 | 3015 |
| 6577 | 3241 | 1667 | 2063 | 1246 | 3050 |
| 6804 | 3278 | 1686 | 2087 | 1260 | 3085 |
| 7000 | 3308 | 1702 | 2106 | 1272 | 3115 |
| 7175 | 3337 | 1716 | 2124 | 1283 | 3140 |
| 7350 | 3362 | 1730 | 2141 | 1293 | 3166 |
| 7575 | 3398 | 1747 | 2162 | 1306 | 3198 |
| 7800 | 3431 | 1764 | 2184 | 1319 | 3229 |
| 8050 | 3466 | 1783 | 2207 | 1333 | 3263 |
| 8300 | 3501 | 1801 | 2230 | 1347 | 3296 |
| 8700 | 3558 | 1830 | 2265 | 1368 | 3349 |
| 9000 | 3599 | 1850 | 2291 | 1384 | 3387 |
| 9300 | 3637 | 1870 | 2316 | 1399 | 3424 |
| 9600 | 3676 | 1890 | 2340 | 1414 | 3460 |
| 9900 | 3713 | 1910 | 2364 | 1428 | 3496 |
| 10200 | 3683 | 1930 | 2388 | 1442 | 3531 |
| 10500 | 3719 | 1949 | 2411 | 1456 | 3565 |
| 10800 | 3754 | 1967 | 2434 | 1470 | 3598 |
| 11100 | 3788 | 1985 | 2456 | 1483 | 3632 |
| 11400 | 3822 | 2003 | 2478 | 1496 | 3664 |
| 11700 | 3855 | 2020 | 2500 | 1509 | 3692 |
| 12000 | 3888 | 2037 | 2521 | 1522 | 3727 |
| 12300 | 3920 | 2054 | 2542 | 1535 | 3758 |
| 12600 | 3952 | 2070 | 2562 | 1547 | 3789 |
| 12900 | 3983 | 2087 | 2580 | 1559 | 3819 |
| 13200 | 4013 | 2103 | 2602 | 1571 | 3848 |
| 13500 | 4044 | 2119 | 2622 | 1583 | 3877 |
| 13800 | 4073 | 2135 | 2641 | 1595 | 3905 |
| 14100 | 4103 | 2150 | 2660 | 1606 | 3933 |
| 14400 | 4132 | 2165 | 2679 | 1618 | 3961 |
| 14700 | 4160 | 2180 | 2697 | 1629 | 3988 |
| 15050 | 4193 | 2197 | 2719 | 1642 | 4020 |
| 15400 | 4225 | 2214 | 2740 | 1654 | 4050 |
| 16150 | 4292 | 2249 | 2783 | 1681 | 4115 |
| 16900 | 4358 | 2283 | 2826 | 1707 | 4178 |
| 17350 | 4396 | 2302 | 2849 | 1721 | 4213 |
| 17800 | 4434 | 2323 | 2875 | 1737 | 4251 |
| 18300 | 4475 | 2344 | 2902 | 1753 | 4290 |
| 18800 | 4516 | 2366 | 2928 | 1769 | 4329 |
| 19400 | 1563 | 2390 | 2959 | 1787 | 4375 |
| 20000 | 4610 | 2415 | 2989 | 1806 | 4419 |
Please note that the above specifications are “general specifications” that pertain to the majority of our production. These specifications should only be used for general, informational purposes. Subject to change without prior notice. For the actual specification, please check with us when order placed. Classification certification like CCS, DNV, BV, LR, NK, KR, RS shall be provided upon request.
