NL Series Stainless Steel Submersible Slurry Sewage Pump
NL Series Stainless Steel Submersible Slurry Sewage Pump Application
NL Series Stainless Steel Submersible Slurry Sewage Pump is mainly used in transporting liquids with high viscosity and mud. Also can behave well if used together with other machines. It is widely applied in distill, pool connection, agricultural irrigation and drain water away, drilling wells, environmental protection, urban engineering, chemical industry, petroleum, pharmacy, mining, papermaking, cement works, steel works, power plants, sewage treatment, market engineering, construction sites, etc.
NL series sewage mud pump is single stage, vertical centrifugal pump, the main parts are diffuser, impeller, pumps, pump shell, support a cylinder, motor seat, motor etc.
In order to reduce weight and the amount of pump shaft is turning, quality carbon steel cold pull park steel manufacturing. The pump is installed in the seat four skeleton oil seal and bushings, prevent axis wear and prolong the service life of the shaft.
This pump is vertical or inclined to use, cover an area of an area small, volute should be buried in work in the media, easy to start.
NL Series Stainless Steel Submersible Slurry Sewage Pump Specification
| Specification | Flow Rate | Head | Power | Rotating Speed |
| m3/h | m | kw | r/min | |
| NL50-8,50A-8 | 20-30 | 8-9 | 1.5 | 1450 |
| NL50-12,50A-12 | 25-38 | 12-14 | 3 | 1450 |
| NL76-9,76A-9 | 50-70 | 9-10 | 3 | 1450 |
| NL65-16,65A-16 | 50-60 | 15-18 | 5.5 | 1450 |
| NL80-12,80A-12 | 80-120 | 11-13 | 7.5 | 1450 |
| NL100-16,100A-16 | 80-100 | 15-17 | 15 | 1450 |
| NL150-12,150A-12 | 100-150 | 11-13 | 18.5 | 1450 |
| NL150-16,150A-16 | 120-180 | 15-20 | 22 | 1450 |
Please note that the above specifications are “general specifications” that pertain to the majority of our production. These specifications should only be used for general, informational purposes. All dimensions and specifications are nominal and are subject to normal manufacturing tolerances. All specifications are subject to change without prior notice. All pictures shown are for illustration purposes only. Actual product may vary. Classification certification like CCS, DNV, BV, LR, NK, KR, RS shall be provided upon request.
