ERNiCr-3 Nickel-Chromium Alloy Wire
ERNiCr-3 Nickel-Chromium Alloy Wire Introduction
ERNiCr-3 (NA82) Nickel-Chromium Alloy Welding Wire is used for welding Inconel alloy 600 and Incoloy 800, overlaying on steel and various dissimilar metal welding applications. Weld processes which can be used include GTAW, GMAW and ASAW.
Dissimilar welding applications include joining Inconel alloys, Incoloy alloys and Incoloy 330 to nickel, Monel alloys, stainless steels and carbon steels. It is also used to join stainless steels to nickel alloys and carbon steels.
Specification
| Grade | American | European |
| ERNiCr-3 | AWS A5.14, ERNiCr-3* ASME II, SFA-5.14, ERNiCr-3 ASME IX, F-No. 43 AMS 5836 |
BS 2901 (NA35) DIN 1736 SG-NiCr20Nb Werkstoff Nr. 2.4806 Europe NiCr20Mn3Nb |
ERNiCr-3 Nickel-Chromium Alloy Wire Size and Packing
| Available in | Diameters | Length |
| Straight Rods(TIG)-inch | .047 .062 .093 .125 | 36 or 39 |
| Straight Rods(TIG)-mm | 1.2 1.6 2.4 3.2 | 915 or 1000 |
| Spooled Wire (MIG)-inch | .030 .035 .040 .045 | Spool |
| Spooled Wire (MIG)-mm | 0.8 0.9 1.0 1.14 | Spool |
ERNiCr-3 Nickel-Chromium Alloy Wire Chemical Composition
| Grade | ERNiCr-3 |
| Ni% | Min 67 |
| C% | Max 0.05 |
| Mn% | 2.5-3.5 |
| Fe% | Max 3.0 |
| S% | Max 0.015 |
| Cu% | Max 0.50 |
| Si% | Max 0.50 |
| Cr% | 18.0-22.0 |
| Ti% | Max 0.75 |
| Nb% | 2.0-3.0 |
| P% | Max 0.015 |
Please note that the above specifications are “general specifications” that pertain to the majority of our production. These specifications should only be used for general, informational purposes. All dimensions and specifications are nominal and are subject to normal manufacturing tolerances. All specifications are subject to change without prior notice. All pictures shown are for illustration purposes only. Actual product may vary.
