Bruce TS Anchor
Bruce TS Anchor Introduction
Marine Bruce TS Anchor is made by Casting Steel. The structure is simple and easy to install, proven high holding power, good stability in both sand and mud seabed. The anchors are of high quality and good stability. The weight of the Anchor is 114kgs to 18000kgs.
The Bruce TS Type Anchor can be supplied with certification from any of the major classification societies.
Bruce TS Anchor Drawing
Bruce TS Anchor Drawing
Bruce TS Anchor Specification
| Anchor Weight | A | B | C | D | E | F | G | H |
| Kg | mm | mm | mm | mm | mm | mm | mm | mm |
| 114 | 1228 | 487 | 197 | 699 | 313 | 935 | 30 | 25 |
| 184 | 1500 | 595 | 241 | 854 | 383 | 1142 | 35 | 27 |
| 294 | 1765 | 700 | 283 | 1005 | 450 | 1344 | 40 | 30 |
| 439 | 2055 | 815 | 330 | 1170 | 504 | 1564 | 40 | 30 |
| 856 | 2435 | 965 | 391 | 1386 | 621 | 1854 | 55 | 43 |
| 3000 | 3843 | 1524 | 616 | 2187 | 980 | 2926 | 95 | 74 |
| 5000 | 4535 | 1798 | 727 | 2582 | 1156 | 3452 | 115 | 89 |
| 9000 | 5525 | 2191 | 886 | 3146 | 1409 | 4206 | 155 | 177 |
| 12000 | 6063 | 2404 | 972 | 3452 | 1546 | 4616 | 155 | 135 |
| 15000 | 6705 | 2659 | 1076 | 3716 | 1710 | 5105 | 155 | 135 |
| 18000 | 6984 | 2769 | 1120 | 3877 | 1780 | 5318 | 155 | 135 |
Please note that the above specifications are “general specifications” that pertain to the majority of our production. These specifications should only be used for general, informational purposes. Subject to change without prior notice. For the actual specification, please check with us when order placed. Classification certification like CCS, DNV, BV, LR, NK, KR, RS shall be provided upon request.
