Admiralty Anchor

Material: Carbon Steel, Casting Steel
Weight: 20kg~20,000kg
Finish: Hot galvanized, Black bitumen paint, anti-rusting paint or customized
Class Certificate: ABS, LR, BV, DNV, GL, NK, KR, IRS, and CCS
Application: Anchorage for the marine and offshore field.

Admiralty Anchor

Admiralty Anchor Introduction

The Admiralty anchor is a conventional type stock anchor. It is widely used in the marine application. The anchor is of high quality and good stability. The weight of Admiralty Anchor is 50KGS-10,000kgs.

The Admiralty Stock Anchor can be supplied with certification from any of the major classification societies

Admiralty Anchor Drawing

Admiralty Anchor Drawing

Admiralty Anchor Drawing

Admiralty Anchor Specification

Weight H h hi B C
Kgs mm mm mm mm mm
50 960 230 42 635 185
75 1105 266 45 710 210
100 1215 293 49 780 230
125 1310 316 52 840 245
150 1395 336 55 900 265
200 1535 370 61 990 290
250 1650 398 65 1065 310
300 1755 423 70 1105 330
400 1930 465 77 1240 365
500 2080 502 84 1335 390
600 2210 330 89 1440 415
700 2330 560 93 1500 440
800 2435 587 97 1570 460
900 2530 610 101 1630 475
1000 2620 633 104 1685 495
1250 2825 680 112 1810 535
1500 3000 725 118 1955 565
2000 3300 797 131 2140 625
2500 3550 857 138 2270 672
3000 3780 912 150 2415 715
3500 3980 860 158 2540 750
4000 4160 1000 155 2650 785
5000 4480 1100 184 2830 800
6000 4740 1113 190 3000 938
7000 5025 1180 200 3165 960
8000 4760 1280 210 3300 980
9000 5450 1330 220 3440 990
10000 5680 1340 230 3600 1086

Please note that the above specifications are “general specifications” that pertain to the majority of our production. These specifications should only be used for general, informational purposes. For the actual specification, please check with us when order placed. Classification certification like CCS, DNV, BV, LR, NK, KR, RS shall be provided upon request.
