20FT Reefer Tank Container
20FT Reefer Tank Container Application
The 20FT Reefer Tank Container is designed to safely transport sensitive, non-hazardous refrigerated liquids such as Milk, Beer, and Juices. These tanks are suitable for expensive cargo’s to be safely transported on long journeys across the country by land or long journey’s sea.
20ft ISO Reefer (Cool) Tank Containers are approved by international statutory authorities for the safe transportation of various hazardous and non-hazardous chemicals, pharmaceuticals, food products like fruit juices, milk, and beverages.
The fully electrical cooling unit is designed to be fully fit within the constraints of the ISO 20 ‘framework. All doors are made of robust stainless steel and offer good protection against damage. The service parts are conveniently fitted and are located behind these stainless steel doors.
The unit is equipped with phase monitoring, which always ensures the correct rotation. As an option, the unit can be designed with 5000 Watt or 9000 Watt heating.
20FT Reefer Tank Container Standard Features
| CAPACITY | Up to 24 CBM |
| MAXIMUM GROSS WEIGHT | 36,000 KG |
| TARE WEIGHT | Up to 4,700 KG |
| WORKING PRESSURE | 4 Bar 58 Psi |
| DESIGN TEMPERATURE | -40C to 130C – 40F to 266F |
| MATERIAL | ASTM A240 SS304 or equal |
| DESIGN CODE | CSC, UIC, TIR, AAR 600 (Not registered) |
20FT Reefer Tank Container Fittings
| MANLID | 1×500mm dia low profile manlid |
| RELIEF VALVE | 1×2.5” BSP Relief Valve |
| RELIEF VALVE PROVISION | 1×2.5” BSP Blind Flanged Provision |
| AIRLINE | 1×1.5” BSP Airline Ball Valve with cap |
| BOTTOM DISCHARGE ASSEMBLY | 1×3” 45 deg Cleanflow Style bottom discharge valve assembly (foot valve, butterfly, and cap) with 3” Camlock Provision |
| STEAM HEATING | 6 runs giving 8.5 m2 effective surface area, with 0.75” BSP inlet/outlet cap, Working Pressure at 4 Bar |
| INSULATION | 50mm thick Polyurethane covered 1,8mm white GRP cladding |
| WALKWAY | “F” Style Marine Grade Aluminum Q grating ladder on the right |
| FORKLIFT POCKET | ID 420×150 Saddle Style Corten Steel Forklift Pocket with side protection bar |
| COOLING SYSTEM | Klinge side mounted TCR-109 refrigeration system complete with glycol expansion tank and rear mounted control box |
Below options available for you to choose
GENSET: Use Klinge front mounted TCR-104 refrigeration system and add NMG-112 Genset (suitable for < 23 CBM capacity)
ACCESSORIES: Datalogger; Heater unit
T-CODE: Can upgrade to make it suitable to carry dangerous goods under T-code
20FT Reefer Tank Container
Please note that the above specifications are “general specifications” that pertain to the majority of the tank containers in our production. These specifications should only be used for general, informational purposes.
